High-Performance Euro Cap Assembly Machine for Fast and Accurate Assembly with 99% Satisfactory Rate and 4500-12000 per/hour Capacity

Büyük resim : High-Performance Euro Cap Assembly Machine for Fast and Accurate Assembly with 99% Satisfactory Rate and 4500-12000 per/hour Capacity

Ürün ayrıntıları:

Menşe yeri:	ÇİN
Marka adı:	SENCAN
Sertifika:	CE, ISO9001
Model numarası:	SC-TP-814

Ödeme & teslimat koşulları:

Min sipariş miktarı:	1 Takım
Fiyat:	Negotiate price according to actual situation
Ambalaj bilgileri:	Tahta sandık
Teslim süresi:	90 Gün
Ödeme koşulları:	T/T,L/C
Yetenek temini:	2-20 Takım

İletişim

Detaylı ürün tanımı

Hava basıncı göstergesi:	SMC	Çalışma hızı:	Ayarlanabilir
Çalışma yöntemi:	Pikap/mekanik	Verimlilik oranı:	%95'in üzerinde
operasyon kişisi:	1 kişi	Malzeme:	Paslanmaz çelik
Ürün gücü:	220V	Sıklık:	50/60 Hz
Montaj kapasitesi:	4500-12000 / saat	Operatör:	Bekar
Tatmin edici oran:	Yaklaşık% 99	Uygulanabilir Kapaklar:	Euro Caps
Çalışma Modu:	Yarı otomatik	Mekanizma:	Servo
Vurgulamak:	Fast and Accurate Euro Cap Assembly Machine , 99% Satisfactory Rate Infusion Cap Assembly Machine , 4500-12000 per/hour Automatic Cap Assembly Machine

High-Performance Euro Cap Assembly Machine for Fast and Accurate Assembly

Product Features

Designed for automatic assembly of easy peel foil caps for IV infusion soft bags and bottles
Constructed with stainless steel and aluminum alloy materials, compliant with GMP standards
Independent driving source for each workstation, facilitating easy maintenance
Product-contact surfaces polished for optimal product protection
Automated foil cutting and welding process
Integrated check function after each assembly step to ensure product quality
PLC control system with user-friendly interface, requiring minimal operator training
Servo motor + indexing drive power system for high precision assembly and qualification rates
Pneumatic power system reduces maintenance time and technical requirements
Fully customizable to meet specific product specifications, capacity, and production demands

Technical Specifications

Applicable Products	Peel seal foil caps, foil seal closures and lids
Production Speed	1500-8500pcs/hr (customizable to customer requirements)
Qualified Product Rate	Above 99%
Operation Rate	Above 95%
Power Source	AC380V, 50Hz, 4kw/hr
Dimensions	Varies according to production speed requirements
Weight	Approximately 2000kg
Operator Requirements	3 sets/2 persons, recommended 1 set/person
